24V high pressure hydraulic hose crimper
,Cremper selang hidraulik tekanan tinggi bergerak
,Pemanas selang bertekanan tinggi portabel
24V mesin pengeringan selang MS-P32CS
Deskripsi
MS-P32CS mesin kabel crimping adalah khusus selang crimper yang disediakan oleh mobil 24V motor.
Fitur Utama
1) Dapat dipindahkan di mobil, menyediakan crimping di tempat
2) Komponen berkualitas tinggi, rentang crimping yang besar
3) Cepat meremas dan membuka, produktivitas tinggi
DATA TEKNIS
|
Model |
MS-P32CS Mesin Hydraulic Crimping |
|
Jangkauan Crimping |
14 - 87 (mm) |
|
Kekuatan Crimping |
280 (T) |
|
Ukuran selang |
1/4 - 2,5 (inci) |
|
Max. pembukaan |
31 (mm) |
|
Set mati |
13 |
|
Tipe set mati |
P32 |
|
Tekanan Sistem |
31.5 (Mpa) |
|
Keakuratan |
0.01 (mm) |
|
Pengendalian |
Negara anggota |
|
Tegangan Standar |
24 (V) |
|
Kekuatan motor |
2.2 (KW) |
|
Panjang |
630 (mm) |
|
Lebar |
540 (mm) |
|
Ketinggian |
420 (mm) |
|
Berat badan |
150 (KG) tanpa minyak |
P32 PEMATIKAN PEMATIKAN PEMATIK
|
Tidak. |
Jangkauan Crimping |
Panjang |
|
6* |
6 - 8 mm |
55 |
|
8* |
8 - 10mm |
55 |
|
10* |
10 - 12 mm |
55 |
|
12* |
12 - 14 mm |
55 |
|
14 |
14 - 16mm |
55 |
|
16 |
16 - 19mm |
55 |
|
19 |
19 - 22mm |
55 |
|
22 |
22 - 26mm |
70 |
|
26 |
26 - 30mm |
70 |
|
30 |
30 - 34mm |
70 |
|
34 |
34 - 39mm |
75 |
|
39 |
39 - 45 mm |
75 |
|
45 |
45 - 51 mm |
90 |
|
51 |
51 - 57mm |
90 |
|
57 |
57 - 63mm |
100 |
|
63 |
63 - 69mm |
110 |
|
69 |
69 - 76mm |
110 |
| 74* | 74 - 80 mm | 110 |
| 78* | 78 - 87mm | 110 |
Catatan
- " * " untuk set die non standar;
- Set mati yang disesuaikan tersedia;
- Tegangan 12V tersedia;
Opsional
- Alat Perubahan Cepat
- Cepat ganti Die Set Rack
Satu silinder minyak, dasar mati bevel ganda, akurasi tinggi dan kekuatan crimping
✅ DIE DISET DENGAN KEKASAN yang tinggi
13 set mati untuk selang dari 1/4 sampai 2 inci dengan tekanan tinggi
¢ Mikrometer untuk kontrol diameter
Keakuratan tinggi dengan stabilitas yang baik, mudah untuk diameter diatur, skala besar
Bahan baku baja berkualitas tinggi
¢ Aplikasi
Untuk pembuatan hidraulik selang karet minyak bertekanan tinggi, menekan pipa air atau udara bertekanan rendah, pipa baja
Swaging tabung besi, kawat dan kabel menekan, pembuatan perangkat kunci, dll.
-
