mesin pengikat selang hidraulik bekas 150T
,P16HPU digunakan hidraulik selang crimper
,P16HPU Crimper selang bekas
Layanan mesin pengeringan selang hidrolik MS-P16HPU
Deskripsi
MS-P16HP mesin hydraulic selang crimper dapat digunakan untuk tekanan tinggi selang karet crimping, mengurangi diameter tabung baja, menekan tali kawat, kabel crimping dll
Keuntungan
1. Kapasitas crimping besar dengan ukuran kecil;
2. Kontrol diameter yang sangat akurat;
3. Silinder tempa, kekerasan tinggi;
4. Die set aman menginstal
DATA TEKNIS
| Model | P16HP Mesin Crimping Selang Hidraulik yang Digunakan |
| Jangkauan Crimping | 14 - 47 (mm) |
| Kekuatan Crimping | 150 (T) |
| Ukuran selang | 1/4 - 1 (inci) |
| Max. pembukaan | 20 mm |
| Set mati | 7 |
| Tipe set mati | P16 |
| Tekanan Sistem | 31.5 (Mpa) |
| Keakuratan | 0.01 (mm) |
| Pengendalian | Negara anggota |
| Tegangan Standar |
Pompa manual |
| Kekuatan motor | Pompa manual |
| Panjang | 400 (mm) |
| Lebar | 320 (mm) |
| Ketinggian | 300 mm |
| Berat badan | 32 (Kg) |
P16 Mesin CRIMPER DIE SET
| Tidak. | Jangkauan Crimping | Panjang |
| 6* | 6 - 8 mm | 55 |
| 8* | 8 - 10mm | 55 |
| 10* | 10 - 12 mm | 55 |
| 12* | 12 - 14 mm | 55 |
| 14 | 14 - 16mm | 55 |
| 16 | 16 - 19mm | 55 |
| 19 | 19 - 23mm | 55 |
| 23 | 23 - 27mm | 55 |
| 27 | 27 - 31mm | 55 |
| 31 | 31 - 35mm | 65 |
| 35 | 35 - 41mm | 65 |
Catatan
- * untuk set die non standar;
- Set mati yang disesuaikan tersedia;
- Max. pembukaan adalah pukulan antara set mati benar-benar ditutup dan benar-benar dibuka.
Opsional
- Alat Perubahan Cepat
- Cepat ganti Die Set Rack;
- Kontrol UC;
-
