NC130 Mesin Crimping Selang Rem
,Tampilan yang jelas Mesin Crimping Selang Rem
,NC130
Mesin pemotong selang rem numerik MS-NC130
Deskripsi
MS-NC130 mesin crimper selang rem menggunakan teknologi pembuatan silinder yang paling canggih dan sistem kontrol PLC terkenal, membuat crimping lebih cerdas dan manusiawi.Ini cocok untuk selang karet tekanan tinggi dari 6mm hingga 51mm crimping dengan kekuatan crimping besarBahkan untuk 3 inci selang menekan.
Keuntungan
1. Alat perubahan die set cepat, menghemat waktu;
2Kecepatan penutupan dan pembukaan yang tinggi;
3. Pedal kaki standar untuk membebaskan kedua tangan;
4Struktur kompak tapi kekuatan besar dengan desain yang unik.
DATA TEKNIS
|
Model |
MS-NC130 Mesin Crimping Selang Rem |
|
Jangkauan Crimping |
14 - 87 (mm) |
|
Kekuatan Crimping |
650 (T) |
|
Ukuran selang |
1/4 - 2,5 (inci) |
|
Max. pembukaan |
31 (mm) |
|
Set mati |
13 |
|
Tipe set mati |
P32 |
|
Tekanan Sistem |
31.5 (Mpa) |
|
Keakuratan |
0.01 (mm) |
|
Pengendalian |
Negara anggota |
|
Tegangan Standar |
220 (V) / 380 (V) |
|
Kekuatan motor |
3.75 (KW) |
|
Panjang |
650 (mm) |
|
Lebar |
550 (mm) |
|
Ketinggian |
650 (mm) |
|
Berat badan |
240 (Kg) |
P32 SET PEMANGAT SIPULAN
|
Tidak. |
Jangkauan Crimping |
Panjang |
|
6* |
6 - 8 mm |
55 |
|
8* |
8 - 10mm |
55 |
|
10* |
10 - 12 mm |
55 |
|
12* |
12 - 14 mm |
55 |
|
14 |
14 - 16mm |
55 |
|
16 |
16 - 19mm |
55 |
|
19 |
19 - 22mm |
55 |
|
22 |
22 - 26mm |
70 |
|
26 |
26 - 30mm |
70 |
|
30 |
30 - 34mm |
70 |
|
34 |
34 - 39mm |
75 |
|
39 |
39 - 45 mm |
75 |
|
45 |
45 - 51 mm |
90 |
|
51 |
51 - 57mm |
90 |
|
57 |
57 - 63mm |
100 |
|
63 |
63 - 69mm |
110 |
|
69 |
69 - 78mm |
110 |
Catatan
- * untuk set die non standar;
- Set mati yang disesuaikan tersedia;
- Tegangan khusus 110V, 208V, 240V, 415V tersedia;
-
